| Model | KD-S2-WIFI | |||
| Spec | 8 million pixels 2X400W | |||
| Operation System | Compression Technology | H.265 compression algorithm 32Kbps~2Mbps | ||
| Resolution | 2880*1624 | |||
| Frame rate | 1-25fps | |||
| Video format | PAL | |||
| Signal-to-Noise Ratio | ≥33dB | |||
| CMOS | Support automatic white balance, automatic gain control, automatic backlight compensation | |||
| Lens/Viewing Angle | The horizontal angle of the lower ball is ≈355 degrees, and the vertical angle is ≈90 degrees. | |||
| Compression Type | BaseLine Profile / Main Profile / High Profile | |||
| Coding Standards | Built-in omnidirectional noise reduction microphone and speaker, supports two-way real-time audio transmission, G.711a audio compression standard, adaptive bit stream | |||
| Audio | Audio Input | 1 built-in -33dB microphone | ||
| Audio Output | Built-in 1 speaker 8 ohm 1W | |||
| LED Lighting | White light infrared day and night full color | 6 infrared | 7 white lights | |
| Features | Multipurpose | Day and night full color mode, infrared mode, white light mode, | ||
| Display Features | 2-way recording, 2-way playback. Alert voice, electronic zoom, 2-screen switching, AI human-shaped picture frame, Bluetooth network, electronic zoom, | |||
| Power | Power Way | USB | ||
| Interface | Type-C | |||
| Video Management | Video recording method | Event video, all-day video | ||
| Video storage | Cloud storage service, supports Micro SD card (maximum 128G) | |||
| WIFI Modules | WiFi8188 IEEE802.11b/g/n | |||
| Network | Bluetooth network configuration | Support | ||
| WIFI | 2.4GHZ Single frequency, 10Mbps/100Mbps | |||
| Network port protocol | TCP/IP, UDP, P2P, DNS, DHCP, RTSP | |||
| Alarm | Voice Alarm | Support | ||
| Intelligent tracking | Support | |||
| Custom detection area | Support | |||
| Sound Detection | Support | |||
| Motion Detection | Support | |||
| System Configuration | iOS 7.0, Android 3.0 and above | |||
| System Requirement | Platform monitoring | Support, Android, Apple, tablet, PC client real-time monitoring | ||
| Others | Reset | Onboard button reset, | ||
| Operating humidity | （-10℃~45℃), humidity less than 95% (no condensation) | |||
| Single weight | 0.5KG | |||
| Single packing size | 165*140*120MM | |||
| Number of packing | 50 pcs/ctn | |||
| Outer box size | 650*350*750MM | |||
| Weight of one CTN(including devices) | 26.3KG | |||
| Installation Environment | Wall mount/ceiling mount | |||
